Drag Link 8-98006794-2 For ISUZU 700P NPR 4HK1 Truck 8980067942 ISUZU Truck Parts

Features & Advantages

• OE Quality: Manufactured to strict ISUZU dimensional and strength specifications for perfect fit and function.

• Heavy-Duty Forged Steel: Provides exceptional strength and durability under severe steering loads.

• Precision Taper Connections: Ensures secure, slop-free fitment to the pitman arm and knuckle.

• Greaseable Ball Joints: Allows for regular lubrication, extending service life and preventing premature wear.

• Corrosion-Resistant Coating: Protects against rust and environmental damage.

• Restores Steering Precision: Eliminates steering wander and loose feel.

• Improves Handling: Provides responsive, precise vehicle control.

• Prevents Uneven Tire Wear: Correct steering geometry extends tire life.

• Critical Safety Component: Ensures reliable steering operation.

• Direct Replacement: Simple installation during steering system service.

• Long Service Life: Engineered to withstand the rigors of heavy-duty commercial operation.



Vehicle & Engine Compatibility

This drag link is specifically designed for ISUZU medium-duty trucks. Common applications include:

• ISUZU 700P — Medium-Duty Trucks

• ISUZU NPR — Medium-Duty Trucks (various models)

• ISUZU NPR HD — Heavy-Duty Variants

• ISUZU NQR (select models)

Compatible Engine Models:

• 4HK1 — 5.2L Diesel Engine

Steering System Application:

• Recirculating ball steering gear systems with drag link configurations

Installation Notes

Professional installation required. This is a critical safety component:

1. Raise and secure the vehicle — Safely raise the front of the vehicle and support on jack stands.

2. Remove the front wheels — Remove both front wheels for access to steering components.

3. Remove the old drag link — Disconnect the drag link from the pitman arm and the steering knuckle/tie rod.

4. Mark or measure settings — Note the position of the old drag link for reference (if applicable).

5. Inspect related components — Check the pitman arm, tie rod ends, and steering knuckle for wear or damage; replace as needed.

6. Clean mounting areas — Clean all connection points and remove any debris.

7. Prepare the new drag link — Install grease fittings and apply grease to the ball joints (if not pre-lubricated).

8. Install the new drag link — Connect the drag link to the pitman arm and the steering knuckle/tie rod arm.

9. Install and torque nuts — Install the taper connection nuts and torque to manufacturer specification.

10. Install cotter pins — Install new cotter pins to secure the nuts.

11. Grease the fittings — Apply the recommended grease to all fittings until grease emerges from the joints.

12. Reinstall wheels — Reinstall both front wheels and torque lug nuts to specification.

13. Lower the vehicle — Lower the vehicle to the ground.

14. Check steering operation — Turn the steering wheel lock-to-lock to check for smooth, free operation.

15. Perform wheel alignment — Professional wheel alignment (toe-in adjustment) is mandatory.

16. Road test — Test drive the vehicle to verify straight-line stability and responsive steering.
