OEM-grade Coolant Hose Flange with PA66 + GF30 Construction for Heat and Corrosion Resistance
Basic Properties
Place of Origin:
China
Brand Name:
YIMI
Certification:
ISO/TS16949
Model Number:
Audi A4 A5 A6 Q5
Trading Properties
Minimum Order Quantity:
10 pcs
Price:
Negotiable
Payment Terms:
T/T,
Supply Ability:
10000 pcs/month
Specifications
| Weight: | Approx. 0.06 – 0.07 Kg | Material: | PA66 + GF30 (glass Fiber-reinforced Polyamide) |
| Number of Inlets/Outlets: | 3 | Engine Compatibility: | VW/Audi 1.8 TFSI & 2.0 TFSI/TSI (EA888 Gen 2) |
| Includes: | Seal | Cooling Type: | Engine Coolant Circulation |
| Installation: | Direct OEM Replacement | Thermal Switch Connector: | Yes |
| High Light: | AUDI coolant hose flange,PA66 GF30 coolant flange,corrosion resistant coolant hose |
||
Product Description
Coolant Hose Flange 06H121132H for Audi A4 A5 A6 Q5 1.8T/2.0T — OEM Cooling System Connector
The Coolant Hose Flange with OEM reference number 06H121132H is a verified direct-fit replacement for a wide range of Audi and Volkswagen vehicles equipped with 1.8 TFSI and 2.0 TFSI/TSI engines from the EA888 Gen 2 engine family. This component, also known as an engine coolant outlet or inlet flange, is a critical part of the engine's cooling system, directing coolant flow between the engine and radiator.
The flange routes coolant to the thermostat housing, where the coolant temperature is assessed to ensure an efficient cooling process. These plastic components are subjected to high heat and pressure, leading to cracks and leaks over time. A failing flange can result in coolant leaks, loose connections, and engine overheating.
This OE-spec replacement flange is manufactured to precise OEM dimensions for easy bolt-on installation and reliable hose connections. It is constructed from high-quality materials (PA66 + GF30) and is heat- and corrosion-resistant, ensuring a tight seal and preventing dangerous coolant loss.
| Part Number: | 06H121132H | Product Name: | Coolant Hose Flange |
| Car Model: | Audi A4 A5 A6 Q5 | Engine Model: | EA888 Gen 2 |
| Condition: | 100% Brand New | Size: | Standard |
| Weight: | Standard | Origin: | China Mainland |
| Main Market: | Middle East, Asia, Africa, South America, North America & Europe | ||
| Package: | Neutral Packing Or Make It As Requested | ||
| Material: | High-strength aluminum alloy & precision bearings | Cooling Type: | Engine coolant circulation |
| Installation: | Direct OEM replacement | Quality Standard: | OEM equivalent / ISO quality control |
Vehicle Compatibility
Primary Applications (Audi & Volkswagen Group):
| Brand | Model | Chassis | Engine / Years |
|---|---|---|---|
| Audi | A4 / S4 | B8 (8K2, 8K5) | 1.8 TFSI / 2.0 TFSI (2008-2017) |
| Audi | A4 Allroad | B8 (8KH) | 2.0 TFSI (2012-2015) |
| Audi | A5 / S5 | B8 (8T3, 8F7, 8TA) | 1.8 TFSI / 2.0 TFSI (2008-2017) |
| Audi | A6 | C7 (4G2, 4GC) | 2.0 TFSI (2012-2018) |
| Audi | Q5 | B8 (8RB) | 2.0 TFSI (2009-2017) |
| Volkswagen | Amarok | (2HA, 2HB, etc.) | 2.0 TSI (2010-2022) |
| Volkswagen | Tiguan | -- | 2.0L (2012-2016) |
Engine Codes (Partial List):
- 1.8 TFSI: CABA, CABB, CABD, CDHA, CDHB, CJEB
- 2.0 TFSI: CAEA, CAEB, CDNB, CDNC, CFKA, CNCD, CNCE, CPMA
⚠️ Important: This flange is designed for EA888 Gen 2 engines only. Always verify your vehicle's engine code and original part number before ordering. The flange features a thermal switch connector — ensure compatibility with your vehicle's sensor configuration. This part is a direct replacement for 06H121132E.
Common Failure Symptoms
| Symptom | Description |
|---|---|
| Coolant leaks | Visible coolant puddles under the vehicle or around the flange area |
| Loose connections | Hoses not seating properly at the flange |
| Engine overheating | Temperature gauge rising above normal due to coolant loss |
| Low coolant warning | Dashboard warning light indicating low coolant level |
| Coolant smell | Sweet smell from the engine bay indicating a leak |
⚠️ Ignoring a failing coolant flange can lead to:
- Severe engine damage from overheating
- Warped cylinder head or blown head gasket
- Complete cooling system failure
- Costly engine repairs
Features & Benefits
PA66 + GF30 construction
Glass fiber-reinforced polyamide — resists warping and cracking under high heat and pressure
Precision-engineered to OEM dimensions
Manufactured to exact OE specifications for easy bolt-on installation and reliable hose connections
3-port design with thermal switch connector
Correct configuration for EA888 Gen 2 engines — ensures proper coolant routing and sensor fitment
Heat- and corrosion-resistant
Withstands extreme engine bay temperatures and coolant chemicals — long-lasting durability
Direct OE replacement
No modifications required — matches factory mounting points and hose connections precisely
Comprehensive cross-reference
Matches multiple OEM numbers (06H121132H, 06H121132E) and aftermarket equivalents — simplifies sourcing
Wide vehicle compatibility
Fits Audi A4/A5/A6/Q5 and VW Amarok/Tiguan with 1.8T and 2.0T EA888 Gen 2 engines
Includes seal
Complete installation — no need to purchase separate gaskets or seals
100% quality inspected
Reliable out of the box — each unit verified for dimensional accuracy and seal integrity
Quality Control & Verification
| QC Item | Verification Method |
|---|---|
| Dimensional accuracy | Precision inspection against OE blueprint — ensures proper fit on EA888 engine |
| Material composition | PA66 + GF30 verification — ensures heat and chemical resistance |
| Seal integrity | Seal quality verified — prevents coolant leaks |
| Sensor fitment | Thermal switch connector fitment verified — ensures proper sensor installation |
| Hose connection fitment | Inlet/outlet ports verified — ensures secure hose connections |
| Batch traceability | Each production batch documented with quality certificates |
Installation & Maintenance Recommendations
⚠️ IMPORTANT: Coolant flange replacement requires mechanical competence and proper coolant handling. Professional installation recommended.
Installation Guidelines (Reference VW/Audi workshop manual for complete steps):
- Safety first — allow engine to cool completely before starting work
- Drain the cooling system — capture coolant for proper disposal
- Disconnect the coolant hoses from the old flange
- Disconnect the thermal switch electrical connector
- Remove the mounting bolts securing the flange
- Remove the old flange — note the position of the seal
- Clean the mounting surface thoroughly — remove all old sealant/gasket material
- Compare the new flange with the old unit — verify part number (06H121132H) matches
- Install the new seal (included with the flange)
- Install the new flange into position
- Torque mounting bolts to manufacturer specification
- Reconnect coolant hoses and thermal switch connector
- Refill cooling system with the correct VW/Audi-approved coolant
- Bleed the cooling system to remove air pockets
- Start engine, bring to operating temperature, and check for leaks
Maintenance Schedule:
- Inspect the coolant flange and hoses for leaks during every service
- Replace coolant every 5 years or 100,000 km (or per manufacturer recommendation)
- If the flange has failed, inspect the thermostat and cooling system for contamination
Packaging & Supply
- Individually sealed in protective packaging
- Includes seal
- Packed in branded or plain carton
- Bulk wholesale available in master cartons
- Suitable for: Audi/VW specialist repair shops, independent garages, auto parts distributors
