High Filtration Efficiency Fuel Filter Element with Water Separation and Corrosion-Resistant Construction for Isuzu CYZ52 6WG1 Engine

Premium-quality fuel filter element designed for Isuzu CYZ52 heavy-duty trucks with 6WG1 diesel engine. Direct OEM replacement that ensures clean fuel delivery for optimal engine performance and longevity.

• OE Quality: Manufactured to Isuzu dimensional and filtration standards for perfect fit and performance
• High Filtration Efficiency: Pleated media captures particles as small as 4-5 microns
• Excellent Dirt-Holding Capacity: Large filtration area extends service life
• Water Separation: Effectively separates water from diesel fuel to prevent corrosion
• Corrosion-Resistant Construction: Steel end caps and center tube resist rust and fuel degradation
• Reliable Sealing: Integrated rubber gasket ensures leak-free installation
• Restores Engine Performance: Improves combustion, restores power, reduces smoke, and enhances fuel economy
• Cost-Effective: Affordable replacement protects expensive injection system components

• ISUZU CYZ52 (heavy-duty truck, 6×4 or 8×4 configuration)
• May also fit other Isuzu heavy models with 6WG1 engine (e.g., CXZ, EXZ, CYZ) - verify compatibility

• 6-Cylinder, Inline Diesel
• Displacement: 15.7L (15681cc)
• Application: CYZ52, CXZ, EXZ series

Installation steps for cartridge-type element:

1. Locate the fuel filter housing (usually near the injection pump)
2. Place a drain pan under the filter housing
3. Remove the filter housing cover (using a wrench or socket)
4. Remove the old filter element and discard
5. Clean the housing interior and water separator bowl (if present)
6. Install a new O-ring/gasket (if supplied) on the housing cover
7. Insert the new filter element, ensuring it seats properly
8. Reinstall the housing cover and tighten to specification (do not overtighten)
9. Prime the fuel system using the hand primer (if equipped) until resistance is felt
10. Start engine and check for leaks

• Media Integrity Test: 100% inspection for pinholes, tears, or improper pleat spacing
• Burst Pressure Test: Filter element tested to withstand maximum differential pressure
• Filtration Efficiency Test: Verified using ISO 19438 multipass test
• Dimensional Check: Outer diameter, height, and sealing surface verified against OE samples
• Seal Leak Test: Each filter checked for proper gasket sealing
• Visual Inspection: 100% checked for cosmetic defects or damage
• Packaged Safely: Element sealed in plastic bag, boxed to prevent contamination

• Neutral export packing or customized packaging available
• Carton or wooden case for safe transportation
• Fast delivery for stock items
• Shipping by Express Air or Sea
