KOYO Clutch Release Bearing CT5586ARSE 55x85.6x19.55mm High-temperature Bearing Steel with One-sided Plastic Sealing
Basic Properties
Place of Origin:
China
Brand Name:
YIMI
Certification:
ISO/TS16949
Model Number:
Hino
Trading Properties
Minimum Order Quantity:
10 pcs
Price:
Negotiable
Payment Terms:
T/T,
Supply Ability:
10000 pcs/month
Specifications
| Type: | Single Row Angular-contact Ball Bearing | Outer Diameter: | 85.6 Mm |
| Inner Diameter: | 55 Mm | Sealing: | One-sided Plastic, Contact Type |
| Material: | High-temperature Bearing Steel (GCr15) | Dynamic Load: | 21.3 KN |
| Static Load: | 16.7 KN | Width: | 18.6 Mm |
| High Light: | KOYO clutch release bearing CT5586ARSE,high-temperature bearing steel clutch bearing,HINO truck clutch bearing with sealing |
||
Product Description
KOYO Clutch Release Bearing CT5586ARSE For Hino Ranger 55x85.6x19.55mm
The KOYO Clutch Release Bearing (Model: CT5586ARSE) is a premium-quality direct replacement component designed for Hino Ranger series trucks and compatible commercial vehicles. Manufactured by KOYO (JTEKT), this bearing delivers smooth and reliable clutch disengagement, ensuring optimal vehicle performance.
| Part Number: | CT5586ARSE | Product Name: | Clutch Release Bearing |
| Car Model: | Hino | Engine Model: | - |
| Condition: | 100% Brand New | Size: | Standard |
| Weight: | Standard | Origin: | China Mainland |
| Main Market: | Middle East, Asia, Africa, South America, North America & Europe | ||
| Package: | Neutral Packing Or Make It As Requested | Warranty: | 6 Months |
| Material: | High-strength aluminum alloy & precision bearings | Cooling Type: | Engine coolant circulation |
| Installation: | Direct OEM replacement | Quality Standard: | OEM equivalent / ISO quality control |
Features & Advantages
- Premium KOYO Quality: Manufactured by KOYO (JTEKT), ensuring exceptional reliability and performance
- Precision Angular-Contact Design: Single row angular-contact ball bearing engineered for optimal clutch release performance
- Smooth Rotation: Delivers smooth and precise clutch disengagement
- Durable Construction: High-quality bearing steel construction for excellent wear resistance and long service life
- Sealed Design: One-sided plastic, contact-type sealing protects against contamination and retains lubrication
- Pre-Lubricated: Factory-greased and sealed - maintenance-free and non-lubrication type
- Restores Clutch Operation: Eliminates grinding noise, hard shifting, and clutch drag
- Direct Replacement: Matches OE dimensions - simple installation on the clutch fork or input shaft sleeve
- Trusted Brand: KOYO is a Tier-1 supplier to major automakers worldwide
Vehicle & Engine Compatibility
This clutch release bearing is specifically designed for Hino Ranger series trucks and compatible commercial vehicles.
Hino Vehicle Models:
- Hino Ranger 4C (漫步者) - chassis FC114
- Hino Ranger 5D (漫步者) - chassis GD174A
- Hino Ranger 7D (漫步者) - chassis FF175
Engine Compatibility:
- Hino W04D (5000 CC)
- Hino EH700 (7000 CC)
Cross-Reference / OEM Numbers:
- 31242-1110A
- 31242-110A
Installation Notes
Installation steps (overview):
- Remove transmission - as per clutch replacement procedure
- Remove old release bearing - unclip from the clutch fork or slide off the input shaft sleeve
- Inspect the clutch fork and input shaft sleeve - clean and lubricate contact points with high-temperature grease (small amount)
- Install new release bearing - clip onto the fork or slide onto the sleeve (depending on design). Ensure it moves freely
- Reinstall transmission - align input shaft with clutch disc splines using alignment tool
- Adjust clutch pedal free play (if cable-operated) or bleed hydraulic system (if hydraulic)
- Test drive - listen for bearing noise and check smooth clutch engagement
Quality Control
- Material Verification: High-quality bearing steel composition and hardness tested
- Dimensional Inspection: Inner diameter (55mm), outer diameter (85.6mm), and width (18.6mm) verified against OE specifications
- Load Rating Testing: Basic dynamic (21.3 kN) and static (16.7 kN) load ratings confirmed
- Noise/Vibration Test: Each bearing tested for smooth, quiet operation
- Seal Integrity Test: One-sided plastic sealing verified for proper contamination protection
- Visual Inspection: 100% checked for defects, rust, pitting, or damage
- ISO9001:2008 Certified: Manufacturing processes meet international quality standards
- Packaged Safely: Coated with anti-rust oil, sealed in plastic bag, boxed with foam protection
Packaging and Delivery
- Neutral export packing or customized packaging available
- Carton or wooden case for safe transportation
- Fast delivery for stock items
- Shipping by Express Air or Sea
Inquiry
For pricing, availability, or bulk purchase of the KOYO Clutch Release Bearing CT5586ARSE For Hino Ranger 55x85.6x19.55mm, please contact our sales team for a competitive quote and expert technical support.
