OEM-grade Brake Master Cylinder for Toyota Corolla Axio 1NZ-FE 2012-2015 — Corrosion-resistant Hydraulic Brake Actuator RHD
  • name
  • name

OEM-grade Brake Master Cylinder for Toyota Corolla Axio 1NZ-FE 2012-2015 — Corrosion-resistant Hydraulic Brake Actuator RHD

MOQ: 10 pcs
Price: Negotiable
Standard Packaging: Neutral Package or as customers’ request
Delivery Period: 5-8 Work Days
Payment Method: T/T,Western Union
Supply Capacity: 10000 pcs/month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YIMI
Certification
ISO/TS16949
Model Number
Toyota Corolla Axio (1NZ-FE)
Steering:
Right-Hand Drive (RHD)
Production Period:
05.2012 – 03.2015
Engine Compatibility:
1NZ-FE (1.50L)
Transmission:
CVT / MT
Included Components:
Cylinder Assembly Only (Reservoir, Cap, O-Ring Sold Separately)
Drive Type:
FF / 4WD
Material:
High-strength Aluminum Alloy & Precision Bearings
Cooling Type:
Engine Coolant Circulation
Highlight:

OEM brake master cylinder Toyota Corolla

,

Corrosion-resistant hydraulic brake actuator

,

Toyota Corolla Axio brake cylinder

Product Description
Brake Master Cylinder 47201-52590 For Toyota Corolla Axio (1NZ-FE) — OEM Hydraulic Brake Actuator
Product Overview

The Brake Master Cylinder Assembly with OEM reference number 47201-52590 is a verified direct-fit replacement for the Toyota Corolla Axio (E160) equipped with the 1NZ-FE engine. This cylinder is a critical component of the hydraulic braking system, converting the mechanical force applied to the brake pedal into hydraulic pressure that activates the brakes.

Part Number 47201-52590 Product Name Brake Master Cylinder
Car Model Toyota Corolla Axio Engine Model Toyota 1NZ-FE
Condition 100% Brand New Origin China Mainland
Material High-strength aluminum alloy & precision bearings Quality Standard OEM equivalent / ISO quality control
Brake Master Cylinder 47201-52590 for Toyota Corolla Axio
Vehicle Compatibility

Primary Applications (Toyota Corolla Axio E160):

Model Chassis / Frame Engine Years
Toyota Corolla Axio DBA-NZE164 1NZ-FE 1.5L 05.2012 - 03.2015
Toyota Corolla Axio DBA-NZE161 1NZ-FE 1.5L 05.2012 - 03.2015
Toyota Corolla Axio NRE161 2NR-FKE 1.5L 03.2015 onwards
Important: This brake master cylinder is designed for Right-Hand Drive (RHD) Toyota Corolla Axio models. It is compatible with FF and 4WD drive configurations and CVT and MT transmissions. The 47201-52590 is the correct OEM part for 2012-2015 Corolla Axio with 1NZ-FE engine. Always verify your vehicle's chassis code (NZE161, NZE164, NRE161) and production year before ordering.
Common Failure Symptoms
Symptom Description
Spongy or sinking brake pedal Pedal feels soft or slowly sinks to the floor
Reduced braking performance Longer stopping distances
Brake fluid leaks Visible fluid around the master cylinder or under the vehicle
Brake warning light Dashboard warning light illuminated
Pedal goes to the floor Complete loss of hydraulic pressure
Ignoring a failing brake master cylinder can lead to:
  • Complete brake failure and dangerous driving conditions
  • Increased stopping distances and potential accidents
  • Damage to other brake system components (booster, ABS pump, calipers)
Features & Benefits
Genuine Toyota OEM specification
Manufactured to original equipment standards — ensures perfect fit, reliable performance, and consistent brake feel
Direct OE replacement
No modifications required — matches factory mounting points and hydraulic line connections precisely
Precision-engineered hydraulic system
Converts pedal force into hydraulic pressure with consistent, linear feel — ensures predictable braking response
Superior sealing technology
Prevents fluid leaks and maintains hydraulic pressure — ensures reliable brake operation
Corrosion-resistant construction
Built to withstand harsh conditions — extends service life
Compatible with RHD Corolla Axio
Specifically designed for Right-Hand Drive models — correct fitment for Japanese and other RHD markets
100% quality inspected
Reliable out of the box — each unit verified for dimensional accuracy and seal integrity
Quality Control & Verification
QC Item Verification Method
Dimensional accuracy Precision inspection against OE blueprint — ensures proper fit on Corolla Axio brake booster
Hydraulic function Pressure and leak testing — verifies proper hydraulic pressure generation and seal integrity
Material quality High-grade materials verification — ensures durability and corrosion resistance
Thread inspection Go/no‑go gauge for hydraulic line connections
Batch traceability Each production batch documented with quality certificates
Installation & Maintenance Recommendations
IMPORTANT: Brake master cylinder replacement requires mechanical competence and proper safety precautions. Professional installation strongly recommended.

Installation Guidelines (Reference Toyota workshop manual for complete steps):

  1. Safety first — securely support the vehicle
  2. Disconnect battery negative terminal
  3. Drain brake fluid from the master cylinder reservoir
  4. Disconnect brake lines from the master cylinder
  5. Remove the mounting nuts securing the cylinder to the brake booster
  6. Remove the old master cylinder
  7. Bench bleed the new master cylinder — critical step to remove air before installation
  8. Compare the new cylinder with the old unit — verify part number (47201-52590) and mounting points match
  9. Install the new master cylinder onto the brake booster
  10. Torque mounting nuts to manufacturer specification
  11. Reconnect brake lines and torque to specification
  12. Refill with the correct Toyota-approved brake fluid (DOT 3 or DOT 4)
  13. Bleed the brake system — start from the furthest wheel cylinder and work toward the master cylinder
  14. Verify pedal feel — should be firm with no sponginess
  15. Road test — verify proper braking performance and no leaks

Maintenance Schedule:

  • Inspect the brake master cylinder for leaks during every brake service
  • Replace brake fluid every 2 years or 40,000 km (or per manufacturer recommendation)
  • If the master cylinder fails, inspect the brake booster and ABS system for contamination

Recommended Associated Parts (sold separately):

Part Name OEM Part Number Quantity
Reservoir Sub-Assy, Brake Master Cylinder 47220-52260 1
Cap Assy, Brake Master Cylinder Reservoir Filler 47230-20140 1
Ring, O (For Brake Master Cylinder) 90015-AH002 1
Ring Pin, Brake Master Cylinder 90029-15803 1
Grommet, Master Cylinder Reservoir 90029-48001 2
Packaging & Supply
  • Individually sealed in protective packaging
  • Packed in branded or plain carton
  • Bulk wholesale available in master cartons
  • Suitable for: Toyota specialist repair shops, independent garages, auto parts distributors
Tags:

Toyota RAV4 headlamp assembly,

Toyota Starlet cylinder head with warranty,

Lexus GS350 replacement motor
